Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203
Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203
Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203
اکنون تماس بگیرید

Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203

مقدار حداقل تعداد سفارش : 100 عدد قیمت : Negotiated
جزئیات بسته بندی : جعبه به عنوان نیاز زمان تحویل : 10 روز
شرایط پرداخت : T/T، Western Union، L/C قابلیت ارائه : 10000000 قطعه در ماه
محل منبع: ساخت چین نام تجاری: JR
گواهی: iso9001 شماره مدل: 301

اطلاعات تکمیلی
تایپ کنید: مهر و موم burgmann Roten 37B/L5 سیل مکانیکی مواد: sic sic fkm cer car nbr
تابع: برای پمپ روغن، پمپ آب بسته حمل و نقل: جعبه
کد HS: 848420090 مشخصات: مهر و موم مکانیکی Burgmann BT-AR
گواهی: ISO9001 استاندارد یا غیر دولتی: استاندارد
سبک: مهر و موم مکانیکی جان کرین (Cyclam) PR/DR مکانیکی اندازه: 14-100 میلی متر
برجسته کردن:

Pedrollo CK pump mechanical seal,Single spring mechanical seal V 304,BT AR 301 mechanical seal warranty

,

Single spring mechanical seal V 304

,

BT AR 301 mechanical seal warranty

توضیحات محصول

Single-Spring Mechanical Seal 301 Replace Aesseal B01 Burgmann Bt-Ar



Operations Conditions OF Water Pump Shaft Seal​ :

  1. Structure: Single End
  2. Pressure: Low Pressure Mechanical Seals
  3. Speed: General Speed Mechanical Seal
  4. Temperature: General Temperature Mechanical Seal
  5. Performance: Wear
  6. Standard: DIN24250
  7. Model NO.: Type 301, BT-AR
  8. Balance: Unbalanced
  9. Specification: Inner Diameter: 6 mm to 60 mm
  10. Temperature:-20ºC to +120ºC
  11. Pressure:≤0.6MPa
  12. Speed:≤10m/s

Materials Of Water Pump Shaft Seal:

  • Structural Features: single end, unbalanced, independent direction of rotation, rubber bellow transmission. This component has a compact structure and it is easy to install. The bellow and the spring provide pressure compensation to the seal faces. The rubber bellow design prevents possible radial run-out so the floatabilitiy of the rotary ring is increased.
  • Stationary Ring:Ceramic(Alumina),Silicon Carbide Reaction Bonded
  • Rotary Ring:Q5,Resin Impregnated Carbon Graphite(Furan),Silicon Carbide Reaction Bonded
  • Secondary Seal:Fluorocarbon Rubber(FKM),Nitrile(NBR),Ethylene Propylene(EPDM)
  • Spring and Metal Parts:Stainless Steel
  • Seat Types:
  • Applications:Clean Water



Performance Capabilities:



Temperature
-30℃ to 200℃, dependent on the elastomer
Pressure
Up to 6 bar
Speed
Up to 10 m/s
End play/axial float allowance
±0.1mm
Size
6mm to 70mm
Brand
JR
Face
Carbon, SiC, TC
Seat
Ceramic, SiC, TC
Elastomer
NBR, EPDM, FKM etc.
Spring
SS304, SS316
Metal parts
SS304, SS316
Packing Detail
1.From 8mm to 30mm is packed in plastic sheets grouply and M box.

2.From 32mm to 70mm is wrapped in plastic paper individually then grouply in M box.

3.Individual packing ,1 pc in 1 small box is available as well with cost of packing added.
  • 301mechanical Seals Factory Direct Sale Pump Seal 301 SeriesMechanical Seals Water Seal
  • Enclosed rubber bellows mechanical seal 301 (BT-AR)
  • Equivalent to:
  • Burgmann BT-AR mechanical seal
  • John Crane (Cyclam) PR/DR mechanical seal
  • Flowserve 118 mechanical seal
  • Latty T750 mechanical seal
  • Roten 37B/ L5 mechanical seal
  • Sterling BT mechanical seal
  • Comonly used as the external seal in water cooled APV pumps

Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 0

Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 1

Mechanical Seal BT AR 301 for Pedrollo CK 50 CK 80E CK 90E Pumps CA CE V 304 11516101203 2

We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,

All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.



At the meantime, we could manufacture seals according to your sample or drawing, and design as your request,Customization: Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
